Application Sites

  • Abdomen
  • Superficial
  • Lung
  • Cardiac

Application Directions

• Medical students training in college: Visual understanding of human body structure or ultrasound image study.
• Private clinic: Whole body check.
• Preliminary examination: Home care, family planning.

Specification

Model D2CL
Display Phone Or Tablet Screen
Probe Type Convex Array + Linear Array
Scan Angle / Length Convex 50, Linear 25mm
Frequency Convex Probe 3.2/5.0 MHz, Linear Probe 7.5/10 MHz
Scan Mode B, B/M, Color, PW
Display Depth Convex 90~305mm, Linear 20~100mm
Image Adjust Gain, Depth, DR, Focus, SRI
Measure Length, Area, Velocity, HR, S/D, GA (CRL, BPD, GS, FL, HC, AC), EFW (BPD, FL), LVIDd, LVIDs, EF, SV, Auto Vessel Measure (TAMEAN, Flow, Diam)
Puncture Assist Function In-plane Puncture Guide Line, Out-of-plane Puncture Guide Line, Needle Enhance
Image Frame Rate 20 Frames / Second
Cinplay >50s
Power Built-in Lithium Battery, Wireless or USB Charge 1.5h, Work 1.5h
Working System iOS, Android, Windows
WiFi Type 802.11n / 5G
Dimension 121x53x19mm
Weight 150g

The King Of Cost Performance In Handheld Ultrasound Probe

  • Highest cost-effective: Students can afford it, just like buying a cell phone.
  • One scan whole body: Composed of convex and linear array, it can scan from abdomen to superficial, even heart.
  • Small, light, built in battery: You can easily use it anywhere.
  • Remote training and guidance: Based on intelligent terminal, remote training and guidance can be achieved.

See The Difference Great Image Quality Makes

Easy To Use

  • You can use your own personal device just like your iPhone or iPad to install the app. No need to buy special device.
  • Boot in one second and enter into working status immediately.
  • Simple operation,short learning curve for people without ultrasound experience.
  • High integration, small size, only 150g, can be placed in the pocket, easy to carry.

Both iOS And Android Apps Available

Switch between all your devices with ease.

How It Works

We condense the conventional ultrasound machine into a small circuit board builded-in the probe, small and light,and showing image on app installed in smart phone/tablet through Wifi(internal wifi from probe, no need external Wifi signal)or USB transferring.

  • Make ultrasound easier and more efficient to use.
  • Provide visual images during any clinical procedures.

Waterproof Design

  • In order to avoid cross infection, we specially designed the whole sealing design, which is convenient for you to clean and disinfect.
  • It can reduce medical accidents caused by cross infection, protect you and patients, and reduce hospital related expenses.

Smart Ultrasound

Smallest handheld ultrasound scanner with two probes makes it practical to hold / scan and to store in a pocket.You can carry it from office to office.

  • You can scan from head,heart to foot using the one probe.
  • You can charge the probe with wireless charger.

More Images Of SonoHealth Handheld Ultrasound Probe
